True
Triplex Operation
The Specified performance of operation is independent
with each other (true Triplex) |
| |
Mpeg4 Compression
Average 3~5Kbyte /frame (at CIF, 30fps) |
| |
Network
1 Ethernet port (Static IP/DHCP?DDNS supported)
Support network TX bandwidth Upper limit control
/ Adaptive Video Data Frame rate control under network
condition |
| |
GUI
Full graphic GUI, Virtual keyboard supported |
| |
Recording
Modified Mpeg4 codec
Total Recording Capacity: 120fps
max (NTSC), 100fps(PAL)
Video Resolution: 704 x 480/704x240/352x240
(each can be selected independent with other channels) |
| |
Archiving
AVI file format via CD-RW / USB port |
| |
Simple CMS (Multi
site live monitoring)
Simultaneous each site DVR video
can be monitored through network (Each Channel can
be displayed simultaneously) |
