Description HYR-4832 HYR-4816 HYR-2416 HYR-1216
G
E
N
E
R
A
L
Video (CH) 36 CH 20 CH 16 CH 16 CH
Analog + IP 32 + 4 16 + 4 16 - 4 16 - 4
Display 960 FPS 480 FPS 480 FPS 480 FPS
Recording 480 FPS 480 FPS 240 FPS 120 FPS
Audio N/A 16 CH 2 CH 2 CH
TV-Out N/A 1 CH 1 CH 1 CH
Codec S/W MPEG 4

O
P
T
I
O
N

Sensor In / Out / PTZ 4 / 4 / PTZ 4 / 4 / PTZ 4 / 4 / PTZ 4 / 4 / PTZ
16 / 4 / PTZ 16 / 4 / PTZ 16 / 4 / X 16 / 4 / X
Audio 16CH, 32CH N/A 16 CH 16 CH
TV-Out 4 CH 4 CH N/A N/A
PTZ Option Option Option Option
Loop-Out Option Option Option Option

Description HYC-2432 HYC-2416 HYC-1216 HYC-1204
G
E
N
E
R
A
L
Video (CH) 36 CH 20 CH 20 CH 8 CH
Analog + IP 32 + 4 16 + 4 16 + 4 4 + 4
Display 240 FPS 240 FPS 120 FPS 120 FPS
Recording 240 FPS 240 FPS 120 FPS 120 FPS
Audio N/A 2 CH 2 CH 2 CH
TV-Out 4 CH 1 CH 1 CH 1 CH
Codec S/W MPEG 4
O
P
T
I
O
N
Sensor In / Out / PTZ 4 / 4 / PTZ 4 / 4 / PTZ 4 / 4 / PTZ 4 / 4 / PTZ
16 / 4 / PTZ 16 / 4 / X 16 / 4 / X N/A
Audio 16 CH 16 CH N/A N/A
TV-Out N/A N/A N/A N/A
PTZ Option Option Option Option
Loop-Out Option Option Option Option

Description HYH-9632 HYH-4816
G
E
N
E
R
A
L
Video (CH) 36 CH 16CH
Analog + IP 32 + 4 16 ? 4
Display 960 FPS 480 FPS
Recording 960 FPS 480 FPS
Audio 32 CH 16 CH
TV-Out 1 CH 1 CH
Codec Hardware MPEG 4
O
P
T
I
O
N
Sensor In / Out / PTZ 4 / 4 / PTZ 4 / 4 / PTZ
16 / 4 / X 16 / 4 / X
Audio N/A N/A
TV-Out N/A N/A
PTZ Option Option
Loop-Out Option Option
